JDZX10-20R3
This type of voltage transformer is epoxy resin casting, fully enclosed single-phase indoor type products, suitable for rated frequency 50 (60) Hz, rated voltage of 20kV power system, for voltage measurement, power measurement and relay protection.
Description
Overview：This type of voltage transformer is epoxy resin casting, fully enclosed single-phase indoor type products, suitable for rated frequency 50 (60) Hz, rated voltage of 20kV power system, for voltage measurement, power measurement and relay protection.
Model meaning:
J-voltage transformer
D-single-phase
Z-Cast insulation
X-Remaining winding
10-Design number
R-Built-in fuse
20-Rated voltage(Kv)
Technical parameters: secondary winding frequency withstand voltage 3kV/1min
Category:
10-35kV Voltage Sensor
Keywords:
Current/Voltage transformer
